easySpiral
Automatic plater
Essential features
easySpiral is an automatic plater of Petri dishes. It allows plating of a sample with 300 to 1.3x105 CFU/mL on one Petri dish, without prior dilution. Plated volumes are of 50 and 100 µL.
- Syringe capacity: 1000 µL
- Plating modes: exponential, circle
- Counting range: from 300 to 1.3x105 CFU/mL
- Plating cycle time: 25 seconds
The Spiral method
With the Spiral method, increase your analysis capabilities: without intermediate dilutions, perform standardized automatic plating with a counting range from 100 to 1 x 107 CFU/mL on 1 single Petri dish!
One touch plating
Plate easily and quickly your 90 mm Petri dishes. Choose from 2 plating modes: exponential and circle.
Exponential mode
The exponential mode is a plating in surface with a decreasing surface concentration. Plate 50 µL or 100 µL volume. Obtain a countable Petri dish from 300 to 1.3 x 105 CFU/mL
High speed automation
The fast rotating arm adapts itself to all types of agar without risks of ploughing. It makes it possible to obtain a plating in 25 seconds (disinfection + sample intake + plating).
Applications
easySpiral platers are used for all types of microbiological analyses in the food, pharmaceutical, cosmetic and public research institutes ...
EasySpiral Range Brochure EasySpiral Technical File
